Chevy LT4 All Inclusive Mid-Mount Serpentine System - Stealth Black

LT4 SUPERCHARGED GENERATION V Engine
Mid Mount Serpentine Conversion Kit

All Inclusive WRAPTOR^TM 8 Track System for Chevy LT4 GEN V wet sump applications with air conditioning, power steering and alternator. Designed around LS1 water pump this unique system features a spring loaded Gates tensioner ensuring proper tension during hard acceleration and deceleration while compensating for belt stretch for optimal performance.

All Inclusive Kit Includes:

• 140 Amp Black Plated 1-Wire CS130 Alternator*
• Black Plated Peanut AC Compressor
• AC Compressor Clutch Cover
• Black Plated Aluminum GM Type II Power Steering Pump
• Remote Mount Reservoir with Bracket
• Gates Premium 8 Rib Belt*
• Alternator Pulley & Cover*
• Power Steering Pulley
• Two Piece Billet Aluminum Bracket*
• Universal Alternator Fan*
• High Flow LS Water Pump - Black*
• Crankshaft Pulley w/ Adapter*
• Water Pump Pulley*
• Heavy Duty Spring Loaded Tensioner w/ Cover*
• Idler Pulley (s) w/ Cover*

**Included with all configurations

Compatible with:

• Cadillac C15-V - Present
• Camaro ZL1 2017 - Present

Application Notes:

• Requires OEM Wet Sump Engine (Cadillac CT5-V/Escalade-V/Camaro ZL1)
• Requires OEM Crank Pulley (Cadillac CT5-V/Escalade-V/Camaro ZL1))
• 3.2:1 Supercharger Drive Ratio (8" Crank, 2.5" Supercharger Pulley)
• 2.4" Supercharger Pulley Available
• Hub Adapter for quick change supercharger pulley included
• Utilizes LS2 Water Pump (Included); Requires use of LS2 Thermostat (Not Included)
• Compatible with Hydroboost (Pump Upgrade available)
• Not Compatible with LT5 Engines
• Requires Remote Breather/Catch Can/Air Oil Separator for PCV System (Not Included)

If ordering without accessories, please see the requirements below:

• Alternator - GM CS130 Style Alternator with 6-12 O'clock mounting and 6.6" bolt spacing
• Power Steering Pump - GM Type II Pump
• Compressor - Peanut Style (7B10) Compressor with 8 Rib Clutch
• Water Pump - 5.62" Tall, Reverse Rotation, 5/8" Pilot and Lower Radiator Hose on Passenger Side

CVF Racing offers the most customizable serpentine kits available on the market today. If you need help with ordering or have any questions, feel free to reach out to us at 651-356-8593.
